Automatic filling
AUTOMATIC MODULAR FILLING SOLUTION
ZEFRONFILL L02-L04-L06
Linear System
√ ZEFRONFILL LINEAR SYSTEM is an automatic linear filling system L02 – L04 – L06 for liquid, viscous, and semi-viscous products
√ Robust frame in AISI 304 stainless steel, with all product contact parts in AISI 316L stainless steel.
√ Each filling head driven by an independent stepper motor, preventing line stops and ensuring continuous operation.
√ Movement controlled by Siemens PLC with encoder, granting simple management and constant accuracy on every container.
√ Scalable system: starting from 2 heads up to 6, without replacing the machine.
√ Modular stand-alone design, easily integrable with existing lines.
APPLICATION SECTORS
FILLING RANGE
From 15 ml to 1 L
ACCESSORIES
TECHNICAL SPECIFICATIONS
| Feature | Technical Details |
|---|---|
| Type | Automatic linear filling machine |
| Frame | AISI 304 stainless steel |
| Product contact parts | AISI 316L stainless steel |
| Dosing unit capacity | 250 ml · 500 ml · 1250 ml per head |
| Filling range | From 15 ml up to 1 L (Ø min 28 mm) |
| Dosing system | Independent Stepper motors – Siemens PLC |
| Operator interface | 10" Touch screen |
| Recipe storage & recall | Automatic save/recall |
| Configuration | Stand-alone |
| Format changeover | Automatic adjustments (height, volume, nozzles) |
| Hopper | 60 L standard – other capacities on request |
| Compressed air | 6-8 bar |
| Maintenance | Cleaning cycles |
| Machine weight | 700 kg |
| Power supply | 400 V – Three-phase – 50 Hz |
| Installed power | 4.7 kW |
*Performance values are subject to variation depending on format and product viscosity.
