Thermosealings
√ ZEFRONSEAL R01 is an automatic single-head sealing machine for hermetic closure using controlled heat and pressure.
√ AISI 304 stainless steel frame, with AISI 316L stainless steel product-contact parts, ensuring strength, hygiene, and durability.
√ Designed for the professional sealing of plastic, and aluminum containers, guaranteeing precision and operational reliability.
√ Suitable for small to medium batches: it allows safe sealing of both fragile and rigid materials without additional positioning accessories.
√ Ergonomic interface and high-performance sealing head for intuitive management and consistent results.
√ Compatible with standard sealing films, usable in-line or as a stand-alone workstation.
√ Modular stand-alone design, easily integrable into existing production lines or new plants, according to Zefron’s engineering philosophy.
APPLICATION SECTORS
RANGE
ACCESSORIES
Drop-shaped cutting die
Circular-shaped cutting die
Changeover starwheel
TECHNICAL SPECIFICATIONS
| Feature | Technical Details |
|---|---|
| Type | Automatic modular sealing machine stand-alone configuration |
| Structure | AISI 304 stainless steel – modular, compact structure |
| Compatible containers | Plastic, aluminum – no flanges required |
| Max container diameter | 120 mm |
| Sealing system | Timed, thermo-regulated sealing head with integrated cutting |
| Cutting die | Shaped serrated blade – cut 1.5 mm from the thread |
| Compatible films | Standard sealing films – customizable materials |
| Film system | Unwinder + synchronized rewinder with scrap recovery |
| Operator interface | Ergonomic control panel – adjustable temperature, pressure and time |
| Cycle time | Variable according to container and film – adjustable |
| Integration | Usable in-line or as an autonomous benchtop station |
| Intended use | Professional sealing in cosmetic and chemical industries |
| Machine weight | 500 kg |
| Power supply | 230V single-phase + product pump 400V three-phase |
| Installed power | 1.5 kW |
